TAKE THE REIGNS. Comfortable Dynamic Power Steering turns the Defender MAX DPS into a workhorse that makes your job even easier. Take those lightweight wheels and tires, adaptable storage and get it done.

Engine:

Type - HD9: 65 hp / 59 lb-ft, Rotax® 976 cc, V-twin, liquid cooled

Fuel Delivery System -  Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)

Transmission - HD9: PRO-TORQ CVT with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection Extra-L / H / N / R / P

Drive Train - Selectable Turf Mode / 2WD / 4WD with Visco-Lok† auto-locking front differential

Driving Assistance - CVT Engine Braking ECO™ / ECO™ Off / Work modes Speed Limiter

Power Steering - Dynamic Power Steering (DPS)

Suspensions:

Front Suspension - Double A-arm / 10 in. (25.4 cm) suspension travel

Front Shocks - Twin tube gas charged shocks

Rear Suspension - TTA with external sway bar / 10 in. (25.4 cm) suspension travel

Rear Shocks - Twin tube gas charged shocks

Tire/Wheels:

Front Tires - XPS Trail Force 27 x 9/11 x 14 in.

Rear Tires - XPS Trail Force 27 x 9/11 x 14 in.

Wheels - 14 in. Steel

Brakes:

Front - Dual 220 mm disc brakes with hydraulic twin-piston calipers

Rear - Dual 220 mm disc brakes with hydraulic twin-piston calipers

Technology - N/A

Dimensions/Capacities:

Length - 153.4 in. ( 389.6 cm)

Width - 63.5 in. (161.2 cm)

Height - 75 in. ( 193 cm)

L x W x H - 153.4 x 63.5 x 76 in. (389.6 x 161.2 x x 193 cm)

Wheel Base - 115.5 in. (294 cm)

Ground Clearance - 11 in. (28 cm)

Chassis Cage - Profiled cage ROPS approved

Estimated Dry Weight* - HD9: 1,753 lb (795 kg)

Cargo Box Dimensions - 38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm)

Cargo Box Capacity - 1,000 lb (454 kg) / California only: 600 lb (272.2 kg)

Tailgate Load Capacity - 250 lb (113.4 kg)

Storage Capacity - Total: 3.1 gal (11.7 L)

Towing Capacity - 2,500 lb (1,134 kg)

Payload Capacity - 1,700 lb (771 kg)

Fuel Capacity - 10.6 gal (40 L)

Person Capacity - 6

Features:

Gauge - 4.5 in. wide digital display

Battery - 12-V (18 amp/h)

Magneto - 650-W

Instrumentation - DC outlet (10-A)

Lighting - Front lighting output 140-W, LED tail lights

Winch - N/A

Seat - VERSA-PRO bench seat with passenger seats flipping up Underside hooks

Steering Wheel - Adjustable tilt steering

Protection - Integrated front steel bumper,, HMWPE central skid plate

Hitch Type - 2 in. hitch receiver

Gauge

Type of gauge

4.5 in. wide digital display

Warranty

Factory - 1-year BRP Limited warranty

Extended Service Terms - B.E.S.T. term available up to 30 months
