Adventure, tailored to you

Our lineup of FourTrax Rancher ATVs is unbeatable. With eight models, there’s a perfect fit for every need and budget, renowned for their durability, toughness, and reliability. Choose a Rancher for excellence without exception

Programmed fuel injection

Programmed Fuel Injection (PGM-FI) allows the ATV to start in any condition and provide reliable performance. It utilizes a 34mm throttle body, 12-hole injector, and oxygen sensor for instant fuel mapping adjustment. This ensures trouble-free operation, reduces emissions and improves fuel efficiency.

Semi-dry-sump engine design

The overhead-valve, semi-dry-sump design creates a compact and lightweight engine that improves handling by lowering the center of gravity and increasing ground clearance.

TraxLok®

Experience the ultimate in traction optimization with our TraxLok® system. Three modes, 2WD, 4WD, and 4WD, with locking front differential and Speed Override, enable increased speed in extreme conditions like mud or snow.

Disc brakes

Both Rancher IRS models offer disc brakes on all four corners for excellent stopping performance in all conditions.

Independent Rear Suspension (IRS)

The IRS models have over 8 inches of suspension travel and 9 inches of ground clearance. This provides constant tire contact for better traction and a smooth ride over rough terrain.

Electric Power Steering (EPS)

Available on the EPS models, our Electric Power Steering (EPS) is both speed—and torque-sensitive and excels at reducing steering effort and kickback through the handlebar. This is a big help when riding in rugged terrain like ruts, rocks, and other challenging environments.

Swingarm rear suspension

On select models, the rear swingarm features a solid axle, providing superior capability for towing and hauling. Its long suspension stroke and plush seat let you tackle your favorite trail or the toughest chores in comfort all day.

Shaft drive

Clean, low-maintenance, and efficient - shaft drive is the perfect choice for high-mileage riders. It eliminates the need for lubrication or adjustment on the trail.

Longitudinal engine layout

By orienting the crankshaft front to back in the chassis, we route the flow of power straight to the wheels without any unnecessary right-angle detours, reducing powertrain friction and putting more grunt to the ground.

Automatic DCT

Available on the Automatic DCT models, the Dual-Clutch Transmission offers strong internals, fast shifts, excellent control, true compression-braking capability, and an automatic program that upshifts and downshifts while you concentrate on riding.

Electronic reverse

Available on the Automatic DCT models, this user-friendly single lever is exceptionally handy for seamless forward-to-reverse transitions—perfect for tasks like snow plowing that demand repetitive shifts.

In-tank fuel pump

An in-tank design promotes cool operation and prolongs the fuel pump's life.

Wide front driveshaft guards

The driveshaft guards, designed to add even more coverage to the front axles and outboard CV joints, are another example of how Honda engineers sweat the small details to give you one of the best ATVs on the planet.

Honda quality

In addition to all the features on a spec chart, this ATV offers something nobody else can match: our well-deserved reputation for quality, superior engineering, and long-term reliability. It’s part of everything we do.

TrueTimber® Atera Camo

A favorite choice for many riders, our exclusive TrueTimber® Atera Camo is a treatment that helps your ATV blend in with a wide range of environments. Available on the Rancher 4x4, and Rancher 4x4 Automatic DCT IRS EPS models.

Make it yours

Our Honda accessories line is perfect for your new Rancher; it includes winches, heated grips, vehicle protection, and more. Use our Honda Pro-Connect™ line to attach or detach accessories quickly and without tools.

Front/rear cargo racks

Unlock limitless versatility with our rugged steel racks. They're designed for easy attachment and removal of Honda Pro-Connect cargo boxes and accessories, giving you added functionality.

1.9-liter front utility box

It's the perfect size for small items you want to access quickly—like a cell phone, GPS, or gloves.

Comfortable seat

This ATV offers a plush seat, an open rider triangle, and superior ergonomics. The thick, soft foam makes it supremely comfortable.

Digital instruments

This ATV offers a range of features to keep you informed on important information while you ride. It includes a gear position indicator, speedometer, odometer, trip meter, hour meter, and much more.

Specifications:

Engine

Engine Type - 420cc longitudinally mounted liquid-cooled wet-sump single-cylinder four-stroke

Bore and Stroke - 86.5mm x 71.5mm

Compression Ratio - 9.9:1

Valve Train - OHV; two valves per cylinder

Induction - Programmed Fuel Injection (PGM-FI); 34mm throttle body

Starter - Electric with optional auxiliary recoil

Drive Train

Clutch - Automatic

Transmission - Five-speed automatic Dual-Clutch Transmission (DCT) with reverse

Driveline - Direct front and rear driveshafts with TraxLok® and torque-sensitive front differential

Chassis Suspension Brakes

Front Suspension - Independent double-wishbone; 7.3-inch travel

Rear Suspension - Independent dual-arm; 8.5-inch travel

Front Brake - Dual 193mm discs

Rear Brake - Dual 170mm discs

Front Tires - 24 x 8-12

Rear Tires - 24 x 10-12

Dimensions

Length - 84.5 inches

Width - 47.4 inches

Height - 47.2 inches

Wheelbase - 51.0 inches

Seat Height - 35.4 inches

Ground Clearance - 9.6 inches

Curb Weight - 686 pounds (includes all standard equipment, required fluids and a full tank of fuel)

Fuel Capacity - 3.9 gallons, including 1.3-gallon reserve

Turning Radius - 11.5 feet

Front Rack Capacity - 66 pounds

Rear Rack Capacity - 133 pounds

Other

Model ID - TRX420FA6

Emissions - Meets current EPA and CARB (California) off-road emissions standards.

Available Colors - Hero Red, Blue, TrueTimber® Atera Camo

Important Safety Information - Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly.

Factory Warranty Information

One Year Included - Transferable, limited warranty

Optional Extended - Extended coverage available with a HondaCare Protection Plan
